| Study of Chopper Circuit (SCR Based Jones Chopper) |
| |
|
|
| Study of Chopper Circuit (SCR Based Jones Chopper)
(2222)
|
| Set up consists:
DC unregulated power supply from
100 volt ac, two SCRs, one tapped inductor, one commutation capacitor, pulse firing circuit with separate contorllable on-off
timings and one lamp load. A series wound universal motor for
Built in power supply,230V mains operated Complete with
working manual & patch
cords. |
|
|
